https://1drv.ms/u/c/64c477ca7a0a2233/IQDYcvZ-2ErBTabIbF1TfTaxARvV-hpWqpADh05qdbx_4R0Let me know if this doesn't work
How do I create a recovery drive on my copilot pc
Charles Kausch
0
Reputation points
I tried to create a recovery drive using the windows tool. I have used 64, 128, 256, and 512 gb flash drives, all failed with the “backup system files “ box checked. Is there a way to create a recovery drive with the system files?
Windows for home | Windows 11 | Recovery and backup
-
Charles Kausch 0 Reputation points
2026-04-02T03:30:11.29+00:00 I tried this already, it didn’t work
Sign in to comment
7 answers
Sort by: Most helpful
-
Charles Kausch 0 Reputation points
2026-04-03T11:05:52.71+00:00 -
Ramesh Srinivasan 77,225 Reputation points Independent Advisor2026-04-03T11:36:10.0766667+00:00 The Recovery Drive creator encountered the error 0x800701B1. Error code 0x800701B1 means
A device which does not exist was specified.Chances are the USB stick went to idle mode while the tool was enumerating your files.
Open Device Manager > Expand “Universal Serial Bus controllers”
For each “USB Root Hub” or “Generic USB Hub”:
Right-click > Properties > Power Management tab
Uncheck “Allow the computer to turn off this device to save power”.
Restart Windows.
If that doesn't help, try another USB port. Or if you have a USB mass storage disk, you could use that to see if it works correctly. The contents of the USB disk will be erased during the Recovery Drive creation process.
Sign in to comment -
-
Charles Kausch 0 Reputation points
2026-04-03T10:49:35.7266667+00:00 I am away and I will respond when I return
Header 1 Header 2 Cell 1 Cell 2 Cell 3 Cell 4 -
Ramesh Srinivasan 77,225 Reputation points Independent Advisor
2026-04-03T10:51:47.1833333+00:00 Ok. I'll await your reply.
Regards,
Sign in to comment -
-
Charles Kausch 0 Reputation points
2026-04-02T14:20:53.96+00:00 -
Ramesh Srinivasan 77,225 Reputation points Independent Advisor
2026-04-02T14:23:42.7533333+00:00 Please upload
setupact.logon OneDrive or GoFile.io and post the link here. -
Deleted
This comment has been deleted due to a violation of our Code of Conduct. The comment was manually reported or identified through automated detection before action was taken. Please refer to our Code of Conduct for more information.
-
Ramesh Srinivasan 77,225 Reputation points Independent Advisor
2026-04-03T03:23:33.1266667+00:00 Hi Charles,
If possible, please upload
setupact.logon OneDrive or GoFile.io and post the link here.
Sign in to comment -
-
Ramesh Srinivasan 77,225 Reputation points Independent Advisor
2026-04-02T04:34:19.0633333+00:00 Hi Charles,
Do you get any errors when creating a recovery drive? If so, please post a screenshot. Also check if Windows RE is enabled. To do so, open Command Prompt (admin) and run this command:
reagentc /infoPost the output here.
If you have any log files in the
C:\Windows\Logs\RecoveryDrivefolder, please upload them in your next reply. -
Q&A Assist2026-04-02T03:26:13.95+00:00 AI generated content. This question contains an answer created with AI from Q&A Assist. Learn moreTo create a recovery drive that includes system files on a Windows 11 Copilot PC, use the built-in Recovery Drive tool and ensure the correct options are selected.
Important: Creating a recovery drive erases all data on the USB drive. Use an empty USB drive.
Steps:
- Open the Recovery Drive tool
- Select Start and search for Recovery Drive, then select it.
- Alternatively, run recoverydrive.exe (for example from Run or a command prompt).
- Enable system file backup
- In the Recovery Drive window, make sure Back up system files to the recovery drive is checked.
- Select Next.
- Connect and select the USB drive
- Insert a USB flash drive.
- When it appears in the list, select that drive.
- Select Next.
- Create the recovery drive
- Select Create.
- The tool will format the USB drive and copy the necessary files. This can take some time.
If the process fails with multiple large USB drives, verify that:
- The USB drive is empty (or that its contents can be erased).
- The drive is properly detected and has no hardware issues.
- No other process is using the drive while the tool runs.
Once created successfully, this recovery drive can be used to boot the PC and access Windows Recovery Environment (Windows RE) tools or reinstall Windows by booting from the USB and choosing Recover from a drive.
References:
- Open the Recovery Drive tool
